Parameter category

Parameter details

Parameter category

Parameter details

★System control

Integrated electric-hydraulic drive

Minimum passing pressure

Passable80-120Container trucks under one ton

Rated voltage

AC220V 50Hz

★System dynamic power

350W

Rising time

≤3-45

★Decrease time

≤3- -45

★Working temperature

-35"C-75C (Suitable)

Storage environment

-10C ~65CRainproof, moisture-proof and dust-proof

★Material

304Stainless steel

★Raise and lower the height of the column

600mm

★Standard thickness

6,8,10,12,15,30mm (Optional)

★Diameter selection

168, 219,273mm (Optional)

★Box size

400/1100

★Internal structure

Load-bearing steel beams and columns, anti-collision steel beams and columns3Root guide pole
body
Electric motor movement:Itinerary600mm,The full outer diameter of the oil cylinder60mm,Rod diameter16mm
6kMirror column/withLEDlamp(Acrylic lamp ring)/Reflective film2article/Interface of interlocking device/It can be manually lowered in the event of a power outage

Protection grade

IP68

Weight

150thenKG

★During the upward and downward movement, reverse operations can be carried out as required
★Noise during the operation of the device60Decibel
★Waterproof integrated hydraulic drive
The double seal of the hydraulic cylinder ensures the waterproof level
★Hydraulic drive with built-in hydraulic lock
★PLCControl programming command control system
220VPower switch
Control solenoid valve24V
Remote control range50M-100M (According to the environment)
★The display text on the control box is adjustable(Rise, fall, start
Time control adjustment)
The displayed text is in both Chinese and English
★PLCBuilt-in encryption system
