The networking function of the vehicle underbody safety inspection and scanning system has the following features.

1.Connect to the security prevention system network of the monitoring center

The security system of important institutions is actually a multi-functional real-time emergency control and command system. The management of this system is carried out internallyThe network connection is distributed among the central control hosts in each subsystem, and a distributed operating system is adopted to form a network structure model. In the system, the control hosts of each subsystem are both highly autonomous and mutually cooperative, achieving the sharing of physical and logical resources throughout the entire system, dynamically reorganizing and allocating tasks or functions, and simultaneously implementing parallel distributed programs to meet the high requirements of rapid interconnection response.

2.System networked control

The vehicle underbody safety inspection scanning system can provide network connection services and corresponding software support. The main approach is when multiple are used simultaneously in one areaVehicle chassis safety inspection systemFor the entry and exit of different models at multiple intersections The vehicle undergoes inspection and scanningAt that time, the on-site vehicle underbody safety inspection systems of each security inspection area can be uniformly connected through the integrated platform of the network center for centralized management via the network connection function. A centralized management platform for each checkpoint can be established in the background to achieve multiple functions such as data sharing, image information discrimination, vehicle entry and exit management, and supervision of security inspection work Vehicle chassis safety inspection systemThe data and materials can be uploaded to the network storage service center through the network for centralized preservation.
